IP67 Waterproof LED Power Supply – 18‑30V DC 0.7A Constant Current LED Driver for Outdoor Lighting

IP67 Waterproof LED Power Supply – 18‑30V DC 0.7A Constant Current LED Driver for Outdoor Lighting
Product Overview
The MeanWell XLG series Constant Current LED Power Supply delivers reliable, stable performance for LED lighting systems. Designed with an operating temperature range of -40°C to +80°C, this waterproof IP67-rated driver is ideal for demanding outdoor and industrial environments such as street lights, landscape lights, garden lights, floodlights, tunnel lights.
Key Features
  • The driver provides stable constant current (0.7A), ensuring flicker‑free lighting and extended LED lifespan — ideal for premium LED fixtures.
  • Its IP67 waterproof rating protects against dust and water immersion, making it ideal for outdoor and harsh environment installations.
  • Supports 100‑277V AC wide input voltage, matching global power systems without extra converters.
  • Built with an aluminum housing for superior heat dissipation and mechanical protection.
  • Operates reliably from ‑40°C to +80°C, suitable for extreme weather conditions.
Performance Benefits
Stable & Reliable Operation
Ensures flicker-free, consistent brightness for high-end LED lighting applications requiring precise illumination control.
Energy Efficient
High efficiency design reduces electricity consumption and operating costs while supporting environmental sustainability.
Durable Construction
Robust aluminum housing withstands heat, humidity, and vibrations for extended service life and reduced maintenance.
Versatile Applications
Compatible with various LED lighting products for both residential and commercial lighting installations.
Technical Specifications
ParameterSpecifications
Product NameIP67 Waterproof LED Power Supply – 18‑30V DC 0.7A Constant Current LED Driver for Outdoor Lighting
Power Rating21W
Output Current0.7A
DC Voltage18-30V
Input AC Current0.3A/100-277V
Efficiency≥88%
Waterproof LevelIP67
Operating Temperature-40°C to +80°C
MaterialAluminum Housing
Package Weight0.34kg/pcs
MODELXLG-20-L-□XLG-20-M-□XLG-20-H-□
OUTPUTRATED CURRENT (Default)350mA500mA700mA
CONSTANT CURRENT REGION32.4~54V25.2~42V18~30V
RATED POWER18.9W21W21W
OPEN CIRCUIT VOLTAGE (max.)60V50V40V
CURRENT TOLERANCE±8.0%
OUTPUT CURRENT RIPPLE<20%
SETUP, RISE TIME500ms/150ms @115VAC, 230VAC
LINE REGULATION<±3%
INPUTVOLTAGE RANGE90~305VAC (Please refer to "STATIC CHARACTERISTIC" section)
FREQUENCY RANGE47~63Hz
POWER FACTORPF≧0.97/115VAC, PF≧0.95/230VAC, PF≧0.91/277VAC@full load
(Please refer to "POWER FACTOR (PF) CHARACTERISTIC" section)
TOTAL HARMONIC DISTORTIONTHD< 20%(@load≧50%/115VC,230VAC; @load≧75%/277VAC)
(Please refer to “TOTAL HARMONIC DISTORTION(THD)” section)
EFFICIENCY (Typ.)89%88.50%88%
AC CURRENT0.3A/115VAC 0.2A/230VAC 0.2A/277VAC
INRUSH CURRENT (Typ.)COLD START 5A(twidth=350μs measured at 50% Ipeak) at 230VAC; Per NEMA 410
MAX. No. of PSUs on 16A CIRCUIT BREAKER42 units (circuit breaker of type B) / 42 units (circuit breaker of type C) at 230VAC
LEAKAGE CURRENT<0.75mA/277VAC
NO LOAD POWER CONSUMPTIONNo load power consumption <0.5W
Applications
  • LED Street Lighting
  • Landscape Lighting
  • Garden & Patio Lights
  • Outdoor Floodlights
  • Industrial Outdoor Lighting
LED driver application examples and installation
Shipping & Delivery Informations
ServiceDelivery Time
DHL/UPS/TNT/FEDEX4-5 working days
EMS10-15 working days
HK Post Air Mail Register15-18 working days
Standard Delivery Time3-4 working days
Trade TermsFOB | EXW | CIF | CNF
Sample AvailabilityYES
Shipping and logistics information
