100 Mbps Bidirectional Link Transceiver for Robotics 600Mhz and 1.4Ghz selectable

Introduction

The FDM-6823UG-100Mbps-8 Nodes-30km is a professional-grade, two-way wireless transmission system designed specifically for ensuring wireless data communications for mission-critical unmanned platforms. Based on advanced COFDM + star network point-to-multipoint technology, this compact transceiver enables reliable, low-latency, high-bandwidth video, audio, and data links at distances up to 30km LOS and 3km NLOS.

This model supports a star topology network, with up to 64 transmitters (mobile nodes) communicating simultaneously with a single central receiver, enabling multiple camera angles and real-time capture and broadcast.

High Light

Supports simultaneous multi-device connections: Supports up to 8 nodes, with a master-slave architecture for efficient management.
Dual-band support: Software-controlled switching between the 600 MHz and 1.4 GHz bands optimizes communication performance for diverse environments.
Strong anti-interference capabilities: Built-in frequency hopping sequence (FHSS) and adaptive modulation technology effectively mitigate signal interference and ensure stable communication.
Large bitrate: Supports up to 100 Mbps bandwidth and simultaneous uplink and downlink transmission.
Strong non-line-of-sight capabilities: Provides stable ground-to-ground communication in non-line-of-sight conditions from 500 meters to 3 kilometers.
Adjustable power: Power ranges from 2W to 5W, allowing for flexible adaptation to diverse environments.
2x2 MIMO technology: Utilizes 2x2 MIMO technology to improve data transmission speed and signal stability.

1. High-Speed 100 Mbps Bidirectional Transmission
The radio provides up to 100 megabits per second (Mbps) of full-duplex wireless bandwidth, supporting real-time video, telemetry, and IP data. Uplink and downlink channels operate simultaneously, supporting real-time HD video streaming from multiple race cars while simultaneously transmitting control commands and telemetry data back without latency.

2. Robust Non-Line-of-Sight Capabilities
Designed for high mobility and low-latency operation, this transceiver ensures continuous connectivity between fast-moving unmanned ground vehicles and control centers in non-line-of-sight environments. It supports fast link recovery, automatic frequency adaptation, and robust error correction, ensuring smooth video and data transmission from unmanned platforms in complex environments.

General		Wireless
Technology	Wireless based on TD-LTE Technology Standards	Communication	1T1R 1T2R 2T2R
Video Transmission	1080p HD video transmission, H.264/H.265 adaptive	IP Data transmission	Supports data transmission based on IP packets
Eencryption	ZUC/SNOW3G/AES(128) Optional Layer-2	Data Link	Full duplex communication
Data Rate	Max 100Mbps(Uplink and Downlink)	Up & Down Ratio	2D3U/3D2U/4D1U/1D4U
Range	30km(Air to ground(LOS) UGV: 500meters-3km Ground to ground(NLOS)	Automatic Reconstruction Chain	Automatic link re-establishment after link failure/ re-deploy the network after a link failure
Capacity	8 nodes	Sensitivity
MIMO	2x2 MIMO	1.4GHZ	20MHZ	-102dBm
Transmitting Power	5watts(2W~5W adjustable via software)		10MHZ	-100dBm
Latency	Air interface delay<30ms		5MHZ	-96dBm
Modulation	QPSK, 16QAM, 64QAM	600MHZ	20MHZ	-102dBm
Anti-Jamming	Frequency Hopping and Adaptive Modulation		10MHZ	-100dBm
Bandwidth	1.4Mhz/3Mhz/5Mhz/10MHz/20MHz/40Mhz		5MHZ	-96dBm
Power Consumption	30Watts	Dual Frequency Band(Software Selectable)
Voltage and Current	DC12-30V	1.4Ghz	1420Mhz-1530MHz
Dimension	12.79.41.8cm	600Mhz	566Mhz-678Mhz

Frequently Asked Questions (FAQ):

Q1: What types of communications does the FDM-6823UG support?
A1: The FDM-6823UG supports wireless communication for HD video transmission, data transmission, and serial control signals, providing comprehensive support for a wide range of applications.

Q2: How do I switch frequency bands?
A2: The 600 MHz and 1.4 GHz frequency bands can be easily switched via software, eliminating the need to change hardware. Operation is simple and fast.

Q3: How does the FHSS function work?
A3: Frequency Hopping Separation (FHSS) technology automatically selects the optimal frequency based on received signal strength, signal-to-noise ratio, and other parameters to avoid interference and ensure stable communication.

Q4: Is the FDM-6823UG suitable for high-speed mobile applications?
A4: Yes, the FDM-6823UG can maintain a stable wireless connection even at speeds of up to 300 km/h.

Q5: What is the maximum number of devices that can be connected to each network?
A5: FDM-6823UG supports up to 8 nodes to achieve efficient distributed communication.

Product Tags:


*From:	Your email address is incorrect!
*To:	IWAVE COMMUNICATIONS CO.,LTD
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Categories	UGV Data Link
Brand Name:	IWAVE
Model Number:	FDM-6823UG
Certification:	CE,FCC
Place of Origin:	CHINA
MOQ:	2units
Price:	Negotiable
Payment Terms:	L/C,D/A,D/P,T/T
Supply Ability:	5000units/month
Delivery Time:	10-15days
Packaging Details:	Standard Shipping Carton
Name:	100 Mbps Bidirectional Link Transceiver for Robotics 600Mhz and 1.4Ghz selectable
Frequency:	566-678Mhz+1420-1530Mhz
RF Power:	Max 5Watts
Anti-jamming:	Frequency Hopping Spread Sprectrum
Operate System:	Support Linux/windows/android
Weight:	281g
Encryption:	AES128
Data Rate:	100-120Mbps
Dimension:	12.79.41.8cm
