High Precision Double Layer Roll Forming Machine 0-35M/min Speed 7.5KW

Categories Double Layer Roll Forming Machine
Place of Origin: CHINA
Brand Name: HENGFU
MOQ: 1 Piece
Packaging Details: Plastic Film & Steel Wire Fixed
Delivery Time: 45Days
Payment Terms: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Tile Type: Colored Steel
Certification: CE, SGS
Condition: New
Customized: Customized
Usage: Roof, Wall, Floor
Transmission Method: Hydraulic Pressure
Transmission Mode: One Inch Chain
Cutting Method: Shear of Guide Column
Transport Package: Plastic Film & Steel Wire Fixed
Specification: 6500mmx1300mmx1200mm
Package Size: 650.00cm * 130.00cm * 120.00cm
Package Gross Weight: 7000.000kg
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

High Precision Double Layer Roll Forming Machine 0-35M/min Speed 7.5KW

High-Precision Space-Saving 840-900 Double Layer Roll Forming Machine

The Double Layer Roll Forming Machine seamlessly combines two independent roll forming models into a single, high-performance system. With a scientifically optimized structure, sleek appearance, space-saving design, and simple operation, it is the perfect solution for small workshops, on-site construction, and businesses with limited factory space.

The machine is mainly composed of a feed introduction platform, forming host, forming and shearing device, hydraulic station, and computer control system. Each component is engineered for durability, ensuring stable, long-term operation under continuous production conditions.

Switching between the upper and lower layers is straightforward and efficient. Operators can control each layer separately via the conversion button on the electric control cabinet, or use the clutch system for independent power management, enabling flexible production without downtime.

The upper and lower layer models are fully customizable to meet specific customer requirements. Optional configurations, including ordinary and hydraulic unloading machines, further enhance automation and efficiency, adapting to diverse production needs.

Technical Specifications
Model NODouble layer roll forming machine
ConditionNew
UsageRoof
External dimensions6500mm x 1300mm x 1200mm
Machine frame300H steel frame
Number of rolling mill sets13-11 row molding
Roll material45# steel rough lathe fine lathe outer circle grinding and electroplating treatment during addition
Spindle material45 steel
Spindle diameterΦ70mm (Solid shaft)
Type of DrivenChain drive
Forming Speed0-35M/min
Main motor power7.5KW
Electric control systemPLC
CustomizedCustomized
OriginCangzhou, Hebei
Warranty1 year
Product Gallery
Frequently Asked Questions
How many people are required to operate the machine?
It requires just one operator plus one person to handle the output; for highly automated models, a single person is sufficient.
How long is the warranty period?
The entire machine comes with a 12-month warranty, excluding wear parts.
What types of profiles can you produce?
Trapezoidal roof panels, corrugated sheets, floor decking, C/Z-purlins, columns/beams, hoarding panels, standing seam roofing, etc. We can also customize products according to customer drawings.
Is the length of the discharge rack adjustable?
Yes, our standard telescopic discharge rack can be adjusted to accommodate sheet materials of varying lengths.
How should the machine be stored when not in use for an extended period?
Disconnect the power, clean the machine, apply anti-rust oil, cover it with a dust cover, and store it in a dry environment.
